KJT photoelectric switch is through the change of light intensity into an electrical signal to achieve control.KJT photoelectric switch product range is complete, diffuse reflection type, mirror reflection type, counter-reflective type, cylindrical, square, groove type, relay output, etc. KJT standard photoelectric switch product range is complete, diffuse reflection type, mirror reflection type, counter-reflective type, long-distance type, intelligent type, relay output type, anti-interference, stable performance, comprehensive your needs. Stable, fully meet your needs.
Product type | KJT-FQTR | ||
| Detection distance | 150mm/300mm | ||
| Minimum Detected Objects | Opaque Objects：1 mm | ||
| Shell material | denatured polyaromatic resin (DPR) | ||
| Supply Voltage | 12~24V DC pulsation (P-P) ±10% max | ||
| Consumption Current | Light Receiver:20mA, Light Thrower:10mA | ||
| Response time | 0.5ms max | ||
| Light source | Infrared light (680nm) | ||
| Load supply voltage | 30V DC max. | ||
| Load supply current | 50mA max. | ||
| Insulation resistance | 200mΩ min. (DC500V) | ||
| Withstand voltage | AC1,000V 50/60Hz min | ||
| Vibrations | 10-500Hz Bi-amplitude 3 mmX, Y, Z 2h in each direction | ||
| Impact | 500m/s²X、Y、Z 3 times in each direction. | ||
| Short circuit protection | Yes | ||
| Operating temperature | -25°C- 55°C | ||
| Environmental humidity | 35 to 85% RH | ||
| Suitable for intensity light | ≤5.000Lux max. | ||
| Protection level | IP67 | ||
| Accessories | M2*8 screws, spring washers, flat washers | ||
