KJT- CXTU-822 Explosion-proof Digital Thermometer

brand name：Explosion-proof digital thermometer
model number：KJT- CXTU-822
Temperature range：The default temperature range is -50-200℃, please contact customer service for quotation if you need other temperature range.
Product Diameter：140mm
Dial Diameter：100mm
Installation：Default thread is movable thread M27*2 (thread O.D. 27mm. Pitch 2mm), G1/2, M20X1.5.
power supply：Default is 2 x 5 batteries
Display Color：Black digital display
dial panel：Switched as standard
material (that sth is made of)：Shell, cast aluminum, temperature measurement part of the whole stainless steel 304 materials
protection class：IP66
Explosion-proof symbol：ExdII CT6 Gb
Quick inquiry

Feature
Dimensions
Wiring diagram
Application scenarios

Explosion-proof digital thermometer using cast aluminum shape, temperature measurement part of the full stainless steel 304 material, strong, beautiful and durable, using imported chip assembly, high stability, built-in battery, micro-power consumption, low temperature drift, integrated circuits and LCD, without external power supply, applicability of the new type of strong on-site temperature display instrument, is the traditional on-site pointer bimetallic thermometer, the present would like to replace the product, is widely used in electric power, steel and all kinds of mechanical equipment supporting.

universal suffrage		clarification
KJT- CXTU-822		digital thermometer
clamshell	Cast Aluminum Housing
Accuracy Class	1	1％
Accuracy Class	2	0.5％
process connection	A	20*2
	B	G3/4
	C	Other specify when ordering
Power supply method	N	battery powered
Temperature range	-50+200 ℃	Customer Choice
