Longer Detection Range
Detects targets with 90% reflectivity up to 50 m, and black targets up to 13 m.
PRODUCT OVERVIEW
Make Long-Range Detection More Stable and Reliable
The KJT-HWCJ-50M uses TOF time-of-flight distance measurement rather than relying only on changes in light intensity. It is designed for industrial applications such as logistics conveying, automation equipment, forklift positioning, and material detection.
DIRECT TIME OF FLIGHT
Calculate Target Distance with Time-of-Flight Measurement
The sensor emits infrared light and receives the light reflected by the target, then calculates distance based on the flight time. It maintains stable detection even when target color, surface curvature, or ambient conditions change.
0.05m-50m
905 nm invisible light
Class 3R
NPN / PNP
9-30V DC
IP65
Stronger Interference Resistance
100K lux ambient light immunity enables reliable use in strong outdoor light and high-intensity industrial lighting environments.
Faster Response Speed
Up to 500 Hz switching frequency, suitable for high-speed production lines and fast-moving targets.
Easier Integration and Installation
Compact 48 x 32 x 21 mm design with a weight of only 22.5 g, excluding cable.
CORE ADVANTAGES
Six Core Capabilities for Industrial Applications
From long-range sensing to fast on-site setup, every feature is built around real-world detection stability.
50 m Long-Range Detection
Detection range of 0.05 m to 50 m for 90% reflective targets, and 0.05 m to 13 m for black targets.
Direct TOF Algorithm
Calculates distance using direct time-of-flight measurement, reducing detection interference caused by simple light-intensity variations.
500 Hz High-Speed Response
Meets the needs of high-speed production lines, object counting, and fast-moving target detection.
100K Lux Ambient Light Immunity
Suitable for strong outdoor light and high-intensity industrial lighting, improving stability in challenging operating conditions.
Compact Miniature Design
Compact 48 x 32 x 21 mm body for easy integration and installation inside equipment.
Flexible On-Site Setup
Supports automatic NO/NC setup, two-point teaching, instant response, and delayed response modes.
TECHNICAL PARAMETERS
Technical Data
Parameters are based on the product specification sheet. Tables can be scrolled horizontally on mobile devices.
01
Basic Performance Parameters
| Model | KJT-HWCJ-50M | Measurement Principle | TOF Time-of-Flight |
|---|---|---|---|
| Detection Range | 0.05 m-50 m (90% reflectivity) | Black Target Detection | 0.05 m-13 m (10% reflectivity) |
| Blind Zone | 5cm | Ranging Frequency | 500Hz |
| Repeatability | 1mm | Laser Wavelength | 905 nm (invisible light) |
| Laser Class | Class 3R | Spot / Field-of-View Indicator | 8 mm diameter @ 2 m |
| Ambient Light Immunity | 100K Lux | Detection Method | Infrared time-of-flight detection |
02
Electrical Specifications
| Operating Voltage | 9-30V DC |
|---|---|
| Peak Current | 80mA |
| Average Current | 18mA |
| Power Consumption | 0.43W |
| Output Type | NPN / PNP |
| Protection Rating | IP65 |
03
Environmental and Mechanical Specifications
| Operating Temperature | -20℃ - +55℃ |
|---|---|
| Storage Temperature | -30℃ - +60℃ |
| Relative Humidity | <=75% |
| Dimensions | 48 x 32 x 21mm |
| Weight | 22.5 g (excluding cable) |
| Cable Specification | 0.2 mm² 4-core PVC cable (2 m) |
Note: In the original specification sheet, the row for 8 mm diameter @ 2 m is labeled as "field angle." This page uses "spot / field-of-view indicator" to avoid misinterpreting a diameter value as an angle.
ELECTRICAL CONNECTION
Electrical Connection
Standard 4-core PVC cable with NPN / PNP output support. Cable length and output protocol can be customized according to project requirements.
04
Pin Assignment
| Pin | Wire Color | Function |
|---|---|---|
| 1 | Brown | Power positive, 9-30V |
| 2 | Blue | Power negative, GND |
| 3 | Black | NPN output |
| 4 | White | PNP output |
FUNCTION SETTINGS
Fast Setup for Complex Operating Conditions
Use the setting button to configure normally open, normally closed, and two-point thresholds, with selectable response modes.
AUTO SETTING
Normally Open (NO)
Press and hold for 2.5-7 sAfter successful setup, the green indicator flashes quickly three times.
AUTO SETTING
Normally Closed (NC)
Press and hold for 7-12 sAfter successful setup, the green indicator flashes quickly three times.
TWO-POINT SETTING
Two-Point Teaching Mode
- Press once when the workpiece is absent
- Press once when the workpiece is present
- The system automatically generates the detection threshold
RESPONSE MODE
Response Mode Switching
Instant Response ModeFor detection tasks requiring fast response
Delayed Response ModeDefault mode with anti-chattering capability for complex operating conditions
05
Indicator Status
| Setup Successful | Green indicator flashes 3 times |
|---|---|
| Setup Failed | Orange indicator flashes 3 times |
| Output Active | Orange indicator stays on |
| No Output | Orange indicator off |
APPLICATIONS
Applications
Ideal choice for industrial applications such as logistics conveying, automation equipment, forklift positioning, and material detection.
Conveyor Material Detection
Designed for material identification, presence detection, and continuous sensing on conveyor lines.
Height Detection
Used for detecting changes in material height and providing feedback to automation equipment.
AGV Position Detection
Uses distance feedback to confirm whether an AGV or target has entered the set detection position.
Quantity Detection
Used for continuous material pass-through detection, counting, and position feedback.
Forklift Positioning
Used for forklift positioning and position detection in warehouse logistics operations.
Warehouse Logistics Detection
Suitable for shelves, warehouse positions, and logistics detection scenarios.
Extended Applications
Flexible Line Detection
Automatic Door Control
Fast-Moving Target Detection
INSTALLATION NOTES
Installation Notes
Configure the sensor according to actual operating conditions to further improve detection stability.
Avoid Direct Interference from Transparent Glass
During installation, consider reflection or penetration effects caused by transparent materials.
Avoid Problematic Angles on Highly Reflective Metal
Adjust the sensor mounting angle according to the reflectivity of the target surface.
Allow for Reduced Range on Black Targets
The detection range for black targets is 0.05 m to 13 m (10% reflectivity).
Set Up According to Actual Conditions
Combine response mode and threshold settings to achieve more stable detection results.
-
