KJT-WJ18 Analog displacement sensor
KJT-WJ18 Analog displacement sensor
KJT-WJ18 Analog displacement sensor
KJT-WJ18 Analog displacement sensor

KJT-WJ18 Analog displacement sensor

  • ●：Suitable for detecting displacement, position and distance of metal conductive materials
  • ●：Customer-customizable inductive ranging sensors and controllers
  • ●：Suitable for use in industrial environments: resistant to high temperature, high pressure, and dust
  • ●：Industrial grade rugged structural design
  • ●：Ultra-high resolution and temperature stability
  • ●：A variety of eddy current probes are available to suit various application requirements.
  • ●：Ultra-high measurement frequency meets real-time requirements
  • ●：Suitable for automation equipment integration
  • Quick inquiry


　　When a metal object approaches the sensing surface of the analog sensor, the LC oscillation of the analog sensor is attenuated. This change is used to convert the current output. The size of the output current is directly related to the distance between the metal object and the sensing surface of the analog sensor. Or directly proportional to the relationship (please refer to the relationship between proximity distance and output current curve).

　　Standard test substance：

　　Use a 1mm thick square steel sheet with an electrical soft iron (i.e. A3 steel) whose side length is equal to the diameter of the sensing surface of the analog sensor.

　　Inductive proximity sensors with analog output are electronic signal generators for measuring position deviations and are used in a wide range of applications.

　　For example:--Measurable bends and deflections

　　--Measurable width

　　--Controllable dimensional stability

　　--Controllable positioning

　　--Controllable centering rate or eccentricity

1



ModelKJT-WJ18AKJT-WJ18BKJT-WJ18CKJT-WJ18D
Installation typeFlushNon-FlushNon-FlushNon-Flush
Sensing distance1…4mm0…7mm7…20mm7…20mm

Relationship between distance and output

current

See graphSee graphSee graphSee graph
Wiring diagramPNPPNPPNPPNP
connectφ5 Dingqing extrusion line 2Mφ5 Dingqing extrusion line 2Mφ5 Dingqing extrusion line 2MBuilt-in binding posts
Substitute models with foreign productsR-AIPM/XVPDPA-4BAW030-PF-1-KBI15-CP40-LU

Remark:

   1. For other technical data, please contact us.

   2. The standard detection bodies of various analog sensors are close to the sensing surface. Under specified conditions, their usable distance is proportional to the output current. Please refer to the prepared curve chart for details

of each curve.



2


3

WJ30 (6)

4

WJ30 (1)

WJ30 (2)

WJ30 (2)

忘记0

WJ30 (4)

WJ30 (3)

WJ30 (5)

WJ30 (1)
