Impact acceleration sensor K15G40
Impact acceleration sensor K15G40
Impact acceleration sensor K15G40
Impact acceleration sensor K15G40

Impact acceleration sensor K15G40

  • Product Series：Impact acceleration sensor K15G40
  • Measuring range：±100000g
  • Sensitivity：0.50pC/g
  • Amplitude linearity：±5%
  • Frequency response (+1dB)：1Hz-10,000Hz
  • Operating temperature：-20~+80℃
  • Dimensions：φ13mm x 28mm
  • Housing material：Titanium alloy
  • output method：Overall line/M5
  • Installation method：M6x0.75
  • weight：10g
  • Quick inquiry

          This series of impact acceleration sensors feature light weight, high stiffness, fast response, and wide frequency response, and are suitable for impact, collision, explosion testing and other related applications.


1


Dynamic characteristics

Measuring range

±10000
Sensitivity0.5pC/g
Amplitude linearity+5%
Frequency response (+1dB)1-10,000Hz
Installation resonant frequency40KHz
Operating temperature-20℃~+80℃
Dimensionsφ13mm x 28mm

structure type

Ceramic shear
Install ground insulation

≥10^9Ω

Housing materialTitanium alloy
output methodOverall line/M5
Installation methodM6x0.75
weight10克



14GAI

2


3


4


场景图
