KJT-KZQ-01 Full-featured Light Curtain Controller
- Product Model：KJT-KZQ-01
- Supply Voltage：AC220V±10%
- Respond：100m or less
- Output voltage：DC12V/200Ma
| Voltage | AC220V±10% |
| Power consumption | 10VA |
| Response time | 100m or less |
| Output voltage | DC12V/200Ma |
| Working signal input | NPN open collector input |
| Test signal input | Contact input |
| Main relay output | Dual relay output, two groups of normally open and one group of normally closed AC250V2A (cosΦ=1) |
| Alarm Output | Sound alarm and relay output, normally open a set of DC30V0.3A (cosΦ=1) |
| Indicator light | Fault indicator light (red), safety indicator light (green), power indicator light (yellow) |
| Shell material | ABS engineering plastics |
| Reset time | about 200ms |
| Ambient temperature | When working: -5~+40ºC (but not freezing), when storing: -25~+55ºC |
| Vibration | Vibration frequency: 10~30Hz, amplitude: 0.35mm, 2 hours each in X, Y and Z directions |
| Resistance to radiation electromagnetic fields | Can withstand radiated electromagnetic field interference with a field strength of 1V/m |
| Anti-static discharge | Can withstand electrostatic discharge interference at 2KV voltage |
| Resistant to electrical fast transients | Can withstand electrical fast transient burst interference at 1KV voltage |
| Life span | The internal relay should be used no less than 100,000 times, and the electrical appliance should be used for 10,000 hours. |
| Protection level | IEC IP20 |
