Photoelectric switches are controlled by converting changes in light intensity into electrical signals.KJT photoelectric switches are available in a wide range of products, such as diffuse reflective, specular reflective, counter-reflective, cylindrical, square, slotted, relay outputs, etc. KJT standard photoelectric switches are available in a wide range of products, such as diffuse reflective, specular reflective, relay outputs, etc. KJT standard photoelectric switches are available in a wide range of products, including diffuse reflective, specular reflective, relay outputs, etc.
Product type | KJT-FJ30 | ||
| Reflective mode | Diffuse reflective | ||
| Detection distance | 0.1 | ||
| Distance tolerance | <10%(Sr) | ||
| Shell material | Copper nickel plated or plastic | ||
| Operating voltage | 10-30VDC | ||
| Ripple | ≤10% | ||
| Switching hysteresis | ＜15% | ||
| Light source | Infrared light (880nm) | ||
| Suitable for large output currents | 200mA | ||
| No load current | ≤30mA | ||
| Voltage drop | ≤2.5V | ||
| Sensitivity adjustment | Trimmer 1tum | ||
| Response time | ＜5ms | ||
| Short circuit protection | Yes | ||
| Power-up protection | Yes | ||
| Operating temperature | -25°C- 55°C | ||
| Environmental humidity | 35 to 85% RH | ||
| Suitable for intensity light | ≤10.000Lux | ||
| Protection level | IP66 | ||
