Selection Guide | Key Factors in Selecting KJT Photoelectric Sensors

  • time:2025-07-10 13:23:34
  • Click:0

KJT photoelectric sensors utilize TOF (Time-of-Flight) technology to achieve non-contact distance measurement

by calculating the time difference between laser pulse emission and reflection.

Widely adopted in industrial automation, logistics, automotive manufacturing, and smart infrastructure,

these sensors excel in robust anti-interference performance, high multi-scenario adaptability, and long service life,

serving as a versatile alternative to traditional photoelectric or ultrasonic sensors.

Below are critical factors to consider during selection:


1. Measurement Range and Accuracy


Measurement Range:

Short Range (0.1m–5m): Ideal for precision applications like AGV navigation and equipment positioning.

Medium-Long Range (5m–50m): Suitable for large-scale logistics sorting lines and automated warehouse monitoring.

Accuracy and Resolution: Absolute accuracy of ±30mm within 5.2m, with ±3mm repeatability, meeting stringent industrial standards.

Millimeter-level dynamic detection for high-speed conveyor systems and robotic obstacle avoidance.

lQLPKHIjjc16DYnNAyDNBaiwjleQCrCvkIoITl52QL9iAA_1448_800

2. Laser Specifications and Safety Compliance


Laser Class:

Class 1: Highest safety rating, ideal for environments prioritizing human eye safety.

Class 2: Permits brief eye exposure but requires cautious handling.

Wavelength: 650nm red light (eye-safe), compliant with international safety standards.

Anti-Interference:

Unaffected by target color or material (transparent/metal/black surfaces).

Resists strong ambient light (up to 50,000 Lux), eliminating shading needs in outdoor settings.

484356235_1334130287776056_7060404130747335228_n

3. Environmental Durability


Protection Rating: IP65/IP67-rated for dust/water resistance, suitable for harsh industrial conditions.

Temperature Range: Operates in -20°C to +70°C, ideal for extreme environments.

Vibration Resistance: Compact modular design (33mm×20mm×11mm) withstands mechanical shocks.

1752126496182_通用1

4. Output Interfaces and Smart Features


Output Types:

Digital: NPN/PNP switching signals (NO/NC) for multi-device synchronization.

Analog: 4-20mA/0-10V for PLC/industrial control systems.

Communication: RS485, IO-Link for remote configuration and data monitoring.

Smart Functions:

Auto-Calibration: Compensates for environmental light and temperature fluctuations.

Multi-Target Detection: Simultaneous distance measurement for complex scenarios.


5. Installation and Deployment


Mounting Options: Threaded, rail, or suction cup mounting for flexible integration.

Application Scenarios:

Industrial: Welding quality inspection, robotic arm navigation, semiconductor wafer positioning. Logistics: AGV path planning, stacker height monitoring in automated warehouses.

Smart Infrastructure: Vehicle spacing detection, toll gate synchronization.

1752126418166_通用1

6. Custom Solutions


High-Temperature Models: Up to 120°C tolerance for metallurgy and foundry applications.

Dustproof Design: Sealed optics ensure stability in high-dust environments.

High-Speed Response: 1000Hz sampling rate for millisecond-level detection on moving targets.


Summary


KJT photoelectric sensors leverage TOF technology to deliver exceptional performance in range, adaptability, and intelligence.

They streamline operations by replacing multi-sensor setups, reducing costs, and simplifying maintenance.

For tailored recommendations or technical support, contact KJT’s expert team.

KJT – Your Partner in Precision Sensing
